Precast is utilized to construct both the superstructure and substructures of all types of bridges. Superstructures include: flat slabs, adjacent box beams, pretensioned beams, spliced and curved girders. Whereas substructures include: precast end bents, piles and pile bent caps, water line pile caps, and precast columns.

Learn more about the specific precast components.

Beam Sections and Properties

PCI has developed and proven common Super Structure systems and Beam Shapes and section properties:

AASHTO I Beams (177k, PDF)

AASHTO-PCI Beams (152k, PDF)

Balanced Cantilever (132k, PDF)

Box Shapes (187k, PDF)

Deck Bulb-Tees (164k, PDF)

Double Tee Bridge Beams (157k, PDF)

NeXT Bridge Beams (104k, PDF)

PCI Zone 6 Curved Spliced Girders (1.8mb, PDF)

Slab Shapes (183k, PDF)

Span by Span (162k, PDF)

There are a number of different beam shapes in the U.S. Market. PCI has developed Preliminary Design Charts in accordance with the AASHTO. 2010. AASHTO LRFD Bridge Design Specifications, Fifth Edition with 2011 Interim Revisions. The below chart is a sample of those products. The charts can be accessed in Preliminary LRFD Design Charts which you can download below.

Products	Charts
AASHTO box beams	Charts BB-1 through BB-10
AASHTO box beams	BT-1 through BT-4
Deck bulb-tees	DBT-1 through DBT-2
AASHTO I-beams	IB-1 through IB-6
NEXT Double-tee beams	NEXT-1 through NEXT-6
U-Beams	U-1 through U-5
